电子学报 ›› 2022, Vol. 50 ›› Issue (5): 1218-1226.DOI: 10.12263/DZXB.20210464

• 学术论文 • 上一篇    下一篇

Keystone变换实现方法研究

张亮1,2, 张翔宇3,4(), 王国宏1()

  1. 1.海军航空大学信息融合研究所, 山东 烟台 264001
    2.中国人民解放军94326部队, 山东 济南 250000
    3.海军航空大学航空电子与指挥系, 山东 青岛 266041
    4.中北大学信息与通信工程学院, 山西 太原 030023
  • 收稿日期:2021-04-12 修回日期:2021-11-25 出版日期:2022-05-25
    • 作者简介:
    • 张 亮 男,1987年出生于山东德州.现为海军航空大学信息融合研究所博士研究生.研究方向为雷达抗干扰.E‑mail: 332401479@qq.com
      张翔宇 男,1986年出生于山西太原.现为海军航空大学航空电子与指挥系讲师.研究方向为雷达抗干扰、目标跟踪技术.E‑mail: zxy627289467@sina.com
      王国宏 男,1963年出生,山西沁水人.现为海军航空大学信息融合研究所教授、博士生导师.主要从事多源信息融合、机动目标跟踪、雷达抗干扰等技术研究 Email: wangguohong@vip.sina.com
    • 基金资助:
    • 国家自然科学基金 (61731023); 山东省自然科学基金 (ZR2020QF071); 博士后科学基金 (2021M693003); 泰山学者攀登计划专项经费资助

Research on Keystone Transform Implementation Methods

ZHANG Liang1,2, ZHANG Xiang-yu3,4(), WANG Guo-hong1()

  1. 1.Institute of Information Fusion, Naval Aviation University, Yantai, Shandong 264001, China
    2.Unit 94326 of PLA, Jinan, Shandong 250000, China
    3.Department of Avionics Engineering and Command, Naval Aviation University, Qingdao, Shandong 266041, China
    4.College of Information and Communication Engineering, North University of China, Taiyuan, Shanxi 030023, China
  • Received:2021-04-12 Revised:2021-11-25 Online:2022-05-25 Published:2022-06-18
    • Supported by:
    • National Natural Science Foundation of China (61731023); Natural Science Foundation of Shandong Province, China (ZR2020QF071); China Postdoctoral Science Foundation (2021M693003); A Grant for Special Project in Taishan Scholar “Climbing” Program

摘要:

Keystone变换(Keystone Transform,KT)是一种经典的雷达目标距离走动校正工具,现有诸多实现方法中以基于线性调频Z变换(Chirp-Z Transform,CZT)和快速傅里叶逆变换(Inverse Fast Fourier Transform,IFFT)的“CZT+IFFT”方法计算量最低.本文针对“CZT+IFFT”方法存在的频谱混叠问题,提出修正的“CZT+IFFT”方法,同时运用时间尺度(Time-Scaling,TS)和尺度估计(Scale-Estimation,SE)概念,进一步提出2种梅林域的KT实现方法.仿真试验验证了分析结论的正确性和所提方法的有效性.

关键词: 雷达, Keystone变换, 相参积累, 梅林变换, 线性调频Z变换, 时间尺度, 尺度估计

Abstract:

Keystone transform(KT) is a classical target range migration correction method in radar. Among the existing implementation methods, the method based on the chirp-z transform(CZT) and inverse fast fourier transform(IFFT) has the lowest amount of calculation. Aiming at the spectrum aliasing problem in the above “CZT+IFFT” method, this paper proposes a modified “CZT+IFFT” method. At the same time, appling the concepts of time-scaling(TS) and scale-estimation(SE), the other two KT implementation methods in mellin transform(MT) domain are further proposed. Simulation results verify the correctness of analysis conclusion and the effectiveness of proposed methods.

Key words: radar, Keystone transform, coherent integration, Mellin transform, chirp-z transform, time-scaling, scale-estimation
