基于光路负载均衡和邻域匹配的串扰感知资源分配方法

doi:10.12263/DZXB.20211049

电子学报 ›› 2022, Vol. 50 ›› Issue (11): 2746-2753.DOI: 10.12263/DZXB.20211049

基于光路负载均衡和邻域匹配的串扰感知资源分配方法

刘焕淋, 胡俊岭, 任杰, 胡会霞, 唐畅, 陈浩楠

重庆邮电大学通信与信息工程学院，重庆 400065

收稿日期:2021-08-04 修回日期:2021-11-28 出版日期:2022-11-25
- 作者简介:
- 刘焕淋　女, 1970年2月出生于重庆市.现为重庆邮电大学教授、博士生导师.主要研究方向为光通信技术和网络.E‑mail: liuhl@cqupt.edu.cn
- 基金资助:
- 国家自然科学基金 (51977021); 重庆市自然科学基金面上项目 (2019jcyj-msxmX0613); 重庆市教育委员会科学技术研究项目 (KJQN201900635)

Crosstalk Aware Resource Allocation Method Based on Lightpath Load Balancing and Neighborhood Matching

LIU Huan-lin, HU Jun-ling, REN Jie, HU Hui-xia, TANG Chang, CHEN Hao-nan

School of Communication and Information Engineering，Chongqing University of Posts and Telecommunications，Chongqing 400065，China

Received:2021-08-04 Revised:2021-11-28 Online:2022-11-25 Published:2022-11-19

摘要/Abstract

摘要：

针对空分复用弹性光网络（Space Division Multiplexing-Elastic Optical Networks, SDM-EONs）的芯间串扰和频谱碎片化问题，该文提出一种考虑业务持续时间、光路邻域资源匹配度及芯间串扰的路由频谱纤芯分配算法.在业务的路由选择阶段，该文设计基于光路负载均衡和频谱碎片减少的路由策略；在纤芯选择阶段，设计兼顾纤芯负载及减少纤芯间串扰的纤芯选择方法；在时-频资源块分配阶段，设计考虑时-频资源碎片变化小和邻域匹配度变化小的资源分配方法.仿真结果表明，该文所提算法可以降低网络带宽阻塞率和提高频谱资源的使用效率.

关键词: 资源分配, 串扰感知, 光路负载均衡, 邻域匹配度, 频谱碎片, 带宽阻塞率

Abstract:

To solve the problems of inter-core crosstalk and spectrum fragmentation in space division multiplexing-elastic optical networks(SDM-EONs), a routing spectrum core allocation with holding time, lightpath’s neighborhood matching degree and inter-core crosstalk(TMD-XT-RSCA) is proposed. In the service routing stage, a routing strategy is designed to balance the lightpath’s load and reduce resource fragment. In the core selection, a core selection method is designed to balance the fiber core’s load and decrease inter-core crosstalk. In the time-spectrum block allocation stage, a resource allocation method through considering small change of time-spectrum fragmentation and small change of neighborhood matching degree is designed. The simulation results show that the proposed TMD-XT-RSCA algorithm can reduce the bandwidth blocking probability and improve the spectrum utilization.

Key words: resource allocation, crosstalk aware, lightpath load balancing, neighborhood matching degree, spectrum fragmentation, bandwidth blocking probability

中图分类号:

TN929.11

刘焕淋, 胡俊岭, 任杰, 胡会霞, 唐畅, 陈浩楠. 基于光路负载均衡和邻域匹配的串扰感知资源分配方法[J]. 电子学报, 2022, 50(11): 2746-2753.

LIU Huan-lin, HU Jun-ling, REN Jie, HU Hui-xia, TANG Chang, CHEN Hao-nan. Crosstalk Aware Resource Allocation Method Based on Lightpath Load Balancing and Neighborhood Matching[J]. Acta Electronica Sinica, 2022, 50(11): 2746-2753.

图/表 6

参考文献 17

1	柴蓉, 邹飞, 刘莎, 等. 6G移动通信:愿景、关键技术和系统架构[J]. 重庆邮电大学学报, 2021, 33(3): 337‐347.
	CHAI Rong, ZOU Fei, LIU Sha, et al. 6G mobile communication: vision, key technologies and system architecture[J]. Journal of Chongqing University of Posts and Telecommunications, 2021, 33(3):337‐347. (in Chinese)
2	严朝阳, 方飞, 曹傧, 等. 基于LoRa的物联网数据传输系统研究与设计[J]. 重庆邮电大学学报, 2021, 33(3): 354‐363.
	YAN Chao-yang, FANG Fei, CAO Bin, et al. Research and design of internet of things data transmission system based on LoRa[J]. Journal of Chongqing University of Posts and Telecommunications, 2021, 33(3): 354‐363. (in Chinese)
3	AHMED T, RAHMAN S, FERDOUSI S, et al. Dynamic routing spectrum and modulation format allocation in mixed-grid optical networks[J]. Journal of Optical Communications and Networking, 2020, 12(5): 79‐88.
4	刘焕淋, 杜理想, 陈勇, 等. 串扰感知的空分弹性光网络频谱转换器稀疏配置和资源分配方法[J]. 电子与信息学报, 2020, 42(7): 1718‐1725.
	LIU Huan-lin, DU Li-xiang, CHEN Yong, et al. Crosstalk-aware spectrum converters sparse configuration and resource allocation for space division multiplexing elastic optical networks[J]. Journal of Electronics & Information Technology, 2020, 42(7): 1718‐1725. (in Chinese)
5	FAEZEH Y, AKBAR G R. Novel crosstalk fragmentation-aware algorithms in space division multiplexed elastic optical networks with considering physical layer security[J]. Optical Switching and Networking, 2020, 37(5): 1‐9.
6	鲍宁海, 苏国庆, 陈静波. 恢复时间敏感的光网络混合通路保护算法[J]. 重庆邮电大学学报, 2017, 29(3): 313‐319.
	BAO Ning-hai, SU Guo-qing, CHEN Jing-bo. Recovery-time aware hybrid path protection algorithm in optical networks[J]. Journal of Chongqing University of Posts and Telecommunications, 2017, 29(3): 313‐319. (in Chinese)
7	FAEZEH Y, AKBAR G R, MOHSEN Y N. Fragmentation-aware algorithms for multipath routing and spectrum assignment in elastic optical networks[J]. Optical Fiber Technology, 2019, 53: 1‐15.
8	ATHARI B A, GHFFARPOUR R A, NICKRAYET M, et al. IF-RSCA: intelligent fragmentation aware method for routing, spectrum and core assignment in space division multiplexing elastic optical networks[J]. Optical Fiber Technology, 2019, 50(27): 284‐301.
9	FAEZEH Y, AKBAR GR, AMIN G. Fragmentation and time aware algorithms in spectrum and spatial assignment for space division multiplexed elastic optical networks[J]. Computer Networks, 2020, 174: 107232.
10	CHEN H R, ZHAO Y L. Time-spectrum consecutiveness based scheduling with advance reservation in elastic optical networks[J]. IEEE Communications Letters, 2015, 19(1): 70‐73.
11	ZHANG J, BAO B W, YAO Q Y, et al. 3D fragmentation metric and RCSA scheme for space division multiplexing elastic optical networks[J]. IEEE Access, 2020, 8: 201595‐201605.
12	LI X H, YUAN J L, REN Z B, et al. RMSA algorithm for malleable-reservation requests in elastic optical networks[J]. Optical Fiber Technology, 2020, 57: 102236.
13	LIU Huan-lin, LV Lei, CHEN Yong, et al. Fragmentation-avoiding spectrum assignment strategy based on spectrum partition for elastic optical networks[J]. IEEE Photonics Journal, 2017, 9(5): 7906413.
14	LIU Huan-lin, HU Hao, CHEN Yong, et al. Fragmentation-avoiding spectrum assignment algorithm based on time-spectrum partition for elastic optical networks[J]. Optical Fiber Technology, 2019, 53: 102020.
15	FABRICIO R L, ANTONIO J, JHONATAN R. Inter-core crosstalk aware greedy algorithm for spectrum and core assignment in space division multiplexed elastic optical networks[J]. Optical Switching and Networking, 2019, 33(7): 61‐73.
16	ZHAO Y L, HU L Z, ZHU R J, et al. Crosstalk-aware spectrum defragmentation based on spectrum compactness in space division multiplexing enabled elastic optical networks with multicore fiber[J]. IEEE Access, 2019, 6: 15346‐15355.
17	TANG F X, LI Y C, SHEN G X, et al. Minimizing inter-core crosstalk jointly in spatial frequency and time domains for scheduled lightpath demands in multi-core fiber-based elastic optical network[J]. Journal of Lightwave Technology, 2020, 38(20): 5595‐5607.

参数	含义	数值
η	耦合系数	4×10^-4
r	弯曲半径	50mm
β	传播常数	4×10⁶ m^-1
ω_th	芯间距	45μm
XT_th1	. XT阈值	-14dB
XT_th2	QPSK XT阈值	-18.5dB
XT_th3	8QAM XT阈值	-21dB
XT_th4	16QAM XT阈值	-25dB
XT_th5	32QAM XT阈值	-27 dB
XT_th6	64QAM XT阈值	-34dB

参数	含义	数值
η	耦合系数	4×10^-4
r	弯曲半径	50mm
β	传播常数	4×10⁶ m^-1
ω_th	芯间距	45μm
XT_th1	. XT阈值	-14dB
XT_th2	QPSK XT阈值	-18.5dB
XT_th3	8QAM XT阈值	-21dB
XT_th4	16QAM XT阈值	-25dB
XT_th5	32QAM XT阈值	-27 dB
XT_th6	64QAM XT阈值	-34dB
